Truck-Mounted Scrap Grab on Dayun with Lifting Axle — 8 t, 4-Section Boom (Ref. TMG-DY2501)
Dayun lifting-axle grab truck, 24,500 kg GVW. 8 t four-section knuckle-boom grab with a 3+2 twin-ram grab with bucket teeth, front-mounted single-ram tipping on a 7,000 × 2,400 × 1,500 mm body. Quick-coupler and through sub-frame fitted.
An 8 t four-section knuckle-boom grab on a Dayun chassis with a lifting axle, on a 4,700 + 1,300 mm wheelbase and 24,500 kg GVW.
Complete Specifications
Parameter | Value |
|---|---|
Chassis | |
Model | Dayun, with lifting axle |
Wheelbase | 4,700 + 1,300 mm |
Crane and grab unit | |
Crane capacity | 8 t, four-section knuckle boom |
Grab type | 3+2, twin-ram, with bucket teeth |
Body | |
Cargo box | 7,000 × 2,400 × 1,500 mm |
Tipping | Front-mounted single ram |
Fitted | Quick-coupler (extended piping), through sub-frame |
Weights and dimensions | |
GVW | 24,500 kg |
Overall (L × W × H) | 10,750 × 2,550 × 3,960 mm |
Why this build
The grab is a 3+2 twin-ram unit with bucket teeth, which is the right pattern for scrap steel and short offcuts where material has to be dug out of a pile rather than lifted off the top.
The body measures 7,000 × 2,400 × 1,500 mm and tips through a front-mounted single ram, giving a long low box for light but bulky material. A quick-coupler with extended piping and a through sub-frame are fitted, so the attachment can be changed without re-plumbing the machine.
The lifting axle allows the truck to run on fewer axles when empty and take the full load when the body is filled.
Options: Quick-coupler fitted; alternative attachments subject to confirmation.
