Truck-Mounted Grab on SINOTRUK Wangpai — 6.3 t, 8.2 m Boom, 3+2 Grab, Winch (TMG-WP2502)
SINOTRUK Wangpai grab truck, 3.9 m short wheelbase, 190 hp Weichai Euro VI engine, 9 t rear axle. 6.3 t crane with an 8.2 m boom, 3+2 universal grab with bucket teeth, plus a winch for hauling loads from a distance. Left-hand drive standard; right-hand drive available on request.
Short answer. This is a grab truck on the SINOTRUK Wangpai 5160 chassis with a new 2080 extended cab, a 6.3 t crane and an 8.2 m boom, plus a winch for hauling loads from a distance. The 3+2 universal grab is twin-ram, with bucket teeth and a lifting nose, and maximum lifting capacity is 3,000 kg. A 190 hp Weichai Euro VI engine drives a Fast 8-speed gearbox to a 9 t rear axle, and the 3.9 m wheelbase keeps the overall length at 7,300 mm. Left-hand drive is standard; right-hand drive is available on request.
Published by Truck Crane China — we build truck-mounted cranes, grab trucks and wrecker trucks on Chinese chassis for export.
A grab truck on the SINOTRUK Wangpai 5160 chassis with the new 2080 extended cab, 190 hp Euro VI Weichai engine, Fast 8-speed gearbox and 9 t rear axle. The 3.9 m wheelbase keeps the overall length at 7,300 mm, which is the point of this build — it turns easily on mountain roads.
Left-hand drive (LHD) is standard. Right-hand drive (RHD) is available on request and is built to order.
Complete Specifications
Parameter | Value |
|---|---|
Chassis | |
Steering | Left-hand drive (LHD) standard. Right-hand drive (RHD) available on request. |
Cab | New 2080 extended cab, 3.9 m wheelbase |
Engine | Weichai 190 hp, Euro VI |
Gearbox | Fast 8-speed |
Rear axle | 9 t, model 1534 |
Frame | 245 × (10+8), locally two-layer |
Tyres | 90.00R20 steel-belted |
Equipment | Factory electronically controlled air conditioning |
Crane and grab unit | |
Crane capacity | 6.3 t |
Boom length | 8.2 m |
Grab type | 3+2 universal grab, twin-ram, with lifting nose and bucket teeth |
Control | Electro-hydraulic 1-into-3 valve block |
Hydraulic cooler | Supplied as standard (factory) |
Body | |
Cargo box | 4,100 × 2,300 × 800 mm |
Tipping | Twin-ram tipping |
Steel thickness | Side 3 / floor 5 |
Fitted | Winch |
Dimensions and weight | |
Overall length | 7,300 mm |
GVW | 16,200 kg |
Why this build
The 6.3 t crane has an 8.2 m boom with a 3+2 universal grab on twin rams, with bucket teeth and a lifting nose. Maximum lifting capacity is 3,000 kg and the boom reaches 8 m 2 fully extended.
The 3+2 universal grab covers both duties: scrap steel and iron in recycling yards, and timber or bamboo in the wood trades. A winch is fitted so loads out of crane reach can be pulled in.
The tipping body has a 4,100 × 2,300 × 800 mm box in 3 mm side / 5 mm floor steel. The factory hydraulic cooler is supplied with the truck.
Options: Winch fitted on this unit; remote control and other attachments available on request.
Questions buyers ask about this SINOTRUK Wangpai grab truck with winch
What crane and boom are fitted?
A 6.3 t crane with an 8.2 m boom, carrying a 3+2 universal grab on twin rams with bucket teeth and a lifting nose.
What is the maximum lifting capacity?
3,000 kg, with the boom reaching 8.2 m fully extended.
What does the winch add?
It lets loads out of crane reach be pulled in; it is fitted on this unit.
What engine and axle does it use?
A 190 hp Weichai Euro VI engine through a Fast 8-speed gearbox to a 9 t rear axle (model 1534), on a 3.9 m wheelbase.
What body does it carry?
A 4,100 × 2,300 × 800 mm twin-ram tipping body in 3 mm side / 5 mm floor steel.
What is the gross vehicle weight?
16,200 kg.
